FX Series

Roskamp flaking mills feature quality construction and materials throughout. The unique Roskamp flaker square-bearing housing design assures accurate, consistent flaking and ease of operation.

Outfitted with unique features that come standard on all Roskamp flakers, including agitators, roll end sealing devices and feeders, Roskamp flakers represent the lowest operating-cost solution in the industry.

16", 18", 20", or 24" diameter indefinite chill cast rolls

Self-aligning double-row spherical roller bearings mounted in split pillow block housings

Roll corrugation and speed differential ratios for all applications

Straight-line roll adjust maintains tram throughout full range of adjustment

One-point roll adjustment via machine jack screws maintains roll parallel throughout the full range of adjustment

Stainless steel pin feeder

One-motor V-belt drive

The FX 1800 features 18" diameter indefinite chill cast rolls. FX Series flaking mills are predominantly used for steam flaking small grains in the standard configuration below. These flakers can also be configured for industrial applications or converted into oilseed flakers using the "Optional Features" listed above.

Standard Features

Indefinite chill cast rolls with alloy shafts

Pneumatically operated feed gate

Manually adjustable roll stops

Flow directors that direct product into roll nip

Scrapers with adjustable counterweights to regulate pressure

Separate industrial-duty adjustable motor platform available in right- or left-side drive and choice of "C" flow or "Z" flow configuration

UHMW cheek plates to seal the roll ends
